Traffic Light Poles

Price 5000.0 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

Traffic Light Poles Specification

Beam
Single arm or double arm, custom span

Power
LED, 20-50 W per lamp head depending on configuration

Head Diameter
200 mm, 300 mm, or 400 mm (signal head options)

Dimension (L*W*H)
Custom as per site requirements

Size
Pole height and arm length customizable as per need

Diameter
76 mm to 168 mm (pole girth range)

Product Type
Traffic Light Pole

Material
Mild Steel (MS) with hot-dip galvanization or powder coating

Light Source
High Visibility LED Modules

Height
3 to 12 meters (customizable)

Voltage
220V AC

Power Supply
220V/50Hz AC

Usage
Traffic Signal Support in Roads and Intersections

Protection Level
Corrosion Resistance, UV Resistant

Efficiency
High Luminance with Low Power Consumption

Color Temperature
Red: 620-630 nm, Yellow: 590-595 nm, Green: 505-510 nm

IP Rating
IP65 (Weatherproof)

Color
Standard Black or Custom Finishes

Field Cabling
Concealed internally through the pole body

Pole Thickness
3 mm to 5 mm

Signal Housing Material
Polycarbonate/Aluminium

Wind Load Resistance
Designed to withstand wind speeds up to 180 km/h

Pole Finish
Hot-dip galvanized and powder coated for rust resistance

Reflective Strips
Optional for increased night visibility

Operating Temperature Range
-20C to +60C

Mounting Type
Base plate with anchor bolts or in-ground planting

Controller Compatibility
Compatible with standard traffic controllers

Traffic Light Poles Trade Information

Minimum Order Quantity
10 Pieces

FOB Port
New Delhi

Payment Terms
Cash in Advance (CID), Letter of Credit (L/C), Cash Against Delivery (CAD), Cash Advance (CA)

Supply Ability
1 Piece Per Day

Delivery Time
1 Week

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
STANDARD

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO AND BIS

About Traffic Light Poles

Conical Poles Description

Conical poles are structures that taper from a wider base to a narrower top, forming a cone-like shape. Key features include:

Structural stability: Provides strength and durability.

Wind resistance: Conical shape can reduce wind load.

Aesthetic appeal: Sleek, modern design.

These poles are used in various applications, such as street lighting, flagpoles, or architectural features.Conical Poles Description

Conical poles are structures that taper from a wider base to a narrower top, forming a cone-like shape. Key features include:

Structural stability: Provides strength and durability.

Wind resistance: Conical shape can reduce wind load.

Aesthetic appeal: Sleek, modern design.

These poles are used in various applications, such as street lighting, flagpoles, or architectural features.

Built to Last and Protect

Crafted to excel in challenging outdoor environments, these traffic light poles combine hot-dip galvanization and powder coating for double-layer corrosion resistance. Their IP65 weatherproof rating and UV resistance safeguard your investment against rain, dust, and intense sunlight, ensuring consistent performance and long operational lifespan.

Adaptable Designs for Every Intersection

Choose from various customizable options in pole height (3-12 meters), diameter, and arm type (single or double). The versatile base plate or in-ground mounting ensures compatibility with diverse urban or rural layouts while internal cabling maintains safety and a clean appearance. Signal heads are available in multiple diameters and colors.

FAQ's of Traffic Light Poles:

Q: How are the traffic light poles installed on site?

A: Traffic light poles can be installed using either a base plate with anchor bolts, which secures the pole to a pre-prepared foundation, or by direct in-ground planting, depending on site requirements and project specifications.

Q: What rust and weather resistance features do these poles offer?

A: The poles are manufactured from mild steel and finished with both hot-dip galvanization and powder coating, providing double-protection against rust and corrosion. Their IP65 weatherproof rating shields them from rain, dust, and UV exposure.

Q: What range of heights and pole diameters are available?

A: Pole heights are customizable from 3 to 12 meters, with pole diameters ranging between 76 mm and 168 mm. Custom arm lengths and dimensions can also be provided to fit specific intersection needs.

Q: Where is internal field cabling routed, and why is this beneficial?

A: Field cabling is discreetly routed inside the pole body, protecting cables from weather, vandalism, and accidental damage. This also enhances pole aesthetics and operator safety.

Q: What type of lighting and power efficiency do these poles support?

A: High visibility LED modules are used as the light source, consuming 20-50 W per lamp head depending on configuration. These LEDs deliver high luminance with low power consumption and distinct signal colors for optimal visibility.

Q: Are these traffic light poles compatible with existing traffic control systems?

A: Yes, the poles are designed to be fully compatible with industry-standard traffic controllers, ensuring hassle-free integration into existing road or intersection infrastructure.

Q: What optional features can enhance pole visibility and performance?

A: Optional reflective strips can be added for increased night-time visibility. You can also select between standard black or custom finishes and choose signal head diameters of 200 mm, 300 mm, or 400 mm to match your specific project requirements.
